Philadelphia Streets Department Surveys
2755 result(s). Showing results 1051 to 1100.
View page: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 (Show all on one page)
| Identifer | Preview | Title | Surveyor | Date | Media / Size / Scale | Area / Map Features |
| 268-03 CP |
|
Plan of the revision of the lines and grades of portions of City Plans Nos. 268 and 274 … and the revision of lines and grades of intersecting and boundary streets affected thereby. 42nd & 50th Wards, City of Philadelphia [Ordinance Dec. 13, 1950; confirmed Aug. 6, 1951] | Delaney, Joseph T. | 1951 |
Tracing
32 x 52 in.
1 inch = 100 feet
|
Bounded by Cheltenham Ave., Crescentville Rd., Adams Ave., Godfrey Ave., Front St., 65th Ave. North, and 2nd St.
Topography, stream; shows curving streets replacing gridded streets and preservation of stream valley
|
| 268-04 MTD |
|
Plan of a revision of a portion of Plan No. 268 (This places American & Lawrence Street on Plan) [Ordinance June 23, 1884; confirmed Jan 16, 1888] | Jones, Walter | 1888 |
Mounted
28 x 25 in.
|
Bounded by Nedro Ave. to Clarkson Ave., 5th St. to 2nd St.
Streams, curb elevations
|
| 268-05 MTD |
|
Plan of the revision of lines and grades on portion of City Plan No. 268, Forty-second Ward, Philadelphia [Ordinance March 15, 1892; survey returned and plan confirmed Feb. 3, 1902] | Brinton, Walter | 1902 |
Mounted
34 x 20 in.
|
Bounded by 66th Ave. North, 5th St., Godfrey Ave. and 2nd St.
Topography, streams, building footprints. Oak Lane Reservoir, old road (Green Lane)
|
| 268-06 MTD |
|
Plan for placing on the City Plan Gale St. and Wentz St. from Front St. to Mascher St., Forty-second Ward, Philadelphia [Ordinance May 16, 1910; confirmed Sept. 19, 1910] | Brinton, Walter | 1910 |
Mounted
18 x 17 in.
|
Bounded by Mascher St., Chew Ave., Front St. and Clarkson Ave.
Curb elevations
|
| 268-07 MTD |
|
Plan of revision of lines of American Street from Chew St. to Tabor St. [Ordinance Jan. 22, 1889; confirmed April 1, 1889] | Jones, Walter | 1889 |
Mounted
36 x 14 in.
|
Bounded by Grange Ave., Third St., Tabor Rd. and Second St.
Curb elevations, pencil notes reference Tabor Land Association and Olney Land Association.
|
| 268-08 MTD |
|
Plan for placing on City Plan Lawrence St. from Tabor St. to Sommerville Ave, Forty-second Ward, Philadelphia [Ordinance July 7, 1905; confirmed Nov. 6, 1905] | Brinton, Walter | 1905 |
Mounted
15 x 10 in.
|
Bounded by Tabor Rd., 4th St., Somerville Ave. and 5th St.
Curb elevations
|
| 268-09 MTD |
|
Plan for placing on the City Plan Lawrence Street from Tabor St. to a point about 500 ft. so. of Olney Ave., Forty-second Ward, Philadelphia [Ordinance June 11, 1902; survey returned July 21, 1902; no confirmation date] | Brinton, Walter | 1902 |
Mounted
17 x 11 in.
|
Bounded by Olney Ave., 4th St., Tabor Rd. and 5th St.
Curb elevations, building footprints
|
| 268-10 MTD |
|
Plan for placing Palethorp (formerly Bickley) Street on the City Plan from Chew Ave. to Tabor St., Twenty-second Ward, Philada. [Ordinance Feb. 26, 1891; survey returned Sept. 11, 1899; confirmed Sept. 17, 1900] | Brinton, Walter | 1899 |
Mounted
25 x 13 in.
|
Bounded by Chew Ave., Clinton St., Tabor Rd. and Second St.
Curb elevations
|
| 268-11 MTD |
|
Plan showing the line of Green Lane, in the 22nd Ward of the City of Philadelphia, as established April 1856 | Lightfoot, Jesse | 1856 |
Mounted
10 x 53 in.
|
22nd Ward. Green Lane, from Old York Rd. to beyond New Second St.
Streams, pond, building footprints, graveyard, North Pennsylvania Railroad, Green Lane Station, schoolhouse, property owners and signatures
|
| 269-02 MTD |
|
Plan of the Almshouse Property with topography [Survey returned March 20, 1882] | Jones, William H. | 1882 |
Mounted
42 x 50 in.
|
West Philadelphia. Bounded by Cleveland St., Woodland Ave., Marston St., and Schuylkill River
Topography and building footprints of Almshouse Property, West Philadelphia; railroads, marshland, stream indicated by dotted line
|
| 269-03 MTD |
|
Plan of the Almshouse grounds, Twenty-seventh Ward, Philadelphia. [Resolution Feb 24th, 1872; survey returned Dec. 20, 1873] | Jones, William H. | 1873 |
Mounted
48 x 54 in.
|
West Philadelphia. Almshouse Grounds. Bounded by Woodland Ave., Marston St., Schuylkill River and Cleveland Ave.
River bank, meadow ditches, railroads, property owners, acreages and conveyances, Beaver Run, wharves, bridge, building footprints
|
| 269-04 MTD |
|
Plan of the survey and regulation of that portion of the Twenty-seventh Ward Philadelphia embraced within the Almshouse Grounds [Resolution March 28, 1871; survey returned Dec. 2, 1872; confirmed March 17, 1873] | Jones, William H. | 1872 |
Mounted
47 x 53 in.
|
West Philadelphia. Almshouse Grounds
River bank, railroads, property acreage, Beaver Run, wharf, sewers, building footprints
|
| 269-06 MTD |
|
Plan of that portion of the Almshouse grounds taken by the Delaware Extension of the Penn'a. Rail Road, Twenty-seventh Ward, Philadelphia. Being supplementary to a plan prepared in accordance with a resolution of Councils approved February 24th 1872. | Jones, William H. | 1873 |
Mounted
20 x 35 in.
|
West Philadelphia. Almshouse Grounds.
River bank, low water line, railroad right of way and bridge
|
| 270-01 MTD |
|
[No title. Twentieth Section, 23rd Ward] | Not named | 1880 ca. |
Mounted
87 x 38 in.
|
23rd Ward, 20th Section. Bounded by Delaware River, Robins (Robbins) St., Bristol Turnpike (Frankford Ave.) and Fouse (Foust) St.
Wissinoming Creek, Little Tacony Creek, railroad, soundings, curb elevations
|
| 270-02 CP |
|
Plan of the revision of lines and grades on the Twentieth Section in the Twenty-third Ward Philadelphia [Ordinance Dec. 31, 1883; confirmed on various dates from 1888 to 1891] | Webster, George S. | 1888 |
Tracing
41 x 96 in.
|
23rd Ward, 20th Section. Bounded by Robbins St. to Foust St., Frankford Ave. to Delaware River
Topography, streams, building footprints, ponds, old roads
|
| 270-04 MTD tracing |
|
Plan of the revision of grades of a portion of City Plan No. 270, Thirty-fifth Ward (late Twenty-third Ward) Philadelphia [Ordinance Nov. 30, 1891; "heard" Jan. 18, 1892; confirmed June 20, 1892 and April 24, 1893] | Webster, George S. | 1892 |
Tracing
33 x 31 in.
1 inch = 100 feet
|
Bounded by Robbins St. to Howell St., Walker St. to Tulip St.
Topography, streams, pond, spring, building footprints
|
| 270-29 MTD |
|
Plan of the revision of lines and grades of Delaware Avenue between Sanger St. and Levick St., 23rd & 41st Wards Phila., also revision of grades of streets adjacent to or intersecting same. Portion of City Plan No. 270, 278, 258. [Ordinances July 7, 1914 and Sept. 27, 1918; confirmed Feb. 16, 1920] | Webster, John H., Jr. | 1920 |
Mounted
35 x 52 in.
1 inch = 100 feet
|
Delaware River front. Delaware Avenue and vicinity. Bounded by Delaware River to Tacony St., Levick St. to Sanger St.
Delaware River front, with many footprints of industrial and residential buildings, Lardner's Pt. Pumping Station, pierhead and bulkhead lines, Wissinoming Creek
|
| 270-29 MTD tracing |
|
Duplicate. Plan of the revision of lines and grades of Delaware Avenue between Sanger St. and Levick St., 23rd & 41st Ward, Phila., also revision of grades of streets adjacent to or intersection same. Portion of City Plan No. 270, 278, 258. [Ordinances July 7, 1914 and Sept. 27, 1915; confirmed Feb. 16, 1920] | Webster, John H., Jr. | 1920 |
Tracing
36 x 51 in.
1 inch = 100 feet
|
Northeast Philadelphia. Bounded by Tacony St. to Delaware River, Sanger St. to Levick St.
Building footprints, wharves, railroads, stream; some street lines extended into the river
|
| 271-03 MTD |
|
Plan of the lines and grades in the Fifth Survey District, Philadelphia [Resolution Oct. 23, 1871; survey returned Sept. 1, 1873; confirmed Nov. 23, 1873] | Wolf, John F. | 1873 |
Mounted
76 x 49 in.
|
Bounded by Vine St. to Oxford St. and Frankford Ave., 6th St. to Delaware River
Wharves, Cohocksink Creek and canal, curb elevations. "John H. Dye, Draughtsman"
|
| 271-06 MTD |
|
Plan of Canal Street from Laurel Street to Delaware Avenue, City of Philadelphia [Ordinances March 18, 1878, p. 51; October 24, 1881, page 218, and Dec. 22 1881, page 273; confirmed Dec. 1, 1884] | Not named | 1884 |
Mounted
15 x 21 in.
|
Canal Street, from Laurel St to Delaware Ave.
Curb elevation; Canal Street follows meanders of Cohocksink Creek, which runs in sewer under the street
|
| 271-07 MTD |
|
Plan of Canal Street from Laurel Street to Delaware Avenue, City of Philadelphia [Ordinances March 18, 1878, p. 51; October 24, 1881, page 218, and Dec. 22 1881, page 273; confirmed Dec. 1, 1884] | Not named | 1884 |
Mounted
15 x 21 in.
|
Canal Street, from Laurel St to Delaware Ave.
Curb elevations; Canal Street follows meanders of Cohocksink Creek, which runs in sewer under the street
|
| 272-01 HP |
|
Plan of the revision of lines and grades on City Plan No. 272 bounded by Wolf, 26th, Curtin Streets and the Schuylkill River. 36th Ward. [Ordinances Dec. 19, 1892 and Dec. 28, 1895; confirmed Sept. 16 and Oct. 21, 1912] | Nobré, John M. | 1912 |
Mounted
46 x 64 in.
|
South Philadelphia
Curb elevations
|
| 272-02 HP |
|
Plan of lines and grades between Ritner, Geary and Twenty-Fifth Streets, and the Schuylkill River. 26th Ward [Confirmed Sept. 7, 1874] | Daly, Thomas | 1874 |
Mounted
55 x 57 in.
1 inch = 100 feet
|
South Philadelphia. Bounded by Hartranft St. to Wolf St., 35th to 25th
Schuylkill River, Point Breeze Gas Works, curb elevations, old roads
|
| 272-03 HP |
|
Plan showing the revision of lines and grades over Plan 272 Twenty-sixth Ward, as per ordinance of Councils, March 22nd, 1880 [Confirmed Jan. 21, 1889] | Not named | 1889 |
Mounted
48 x 71 in.
1 inch = 100 feet
|
South Philadelphia. Bounded by 37th to 25th Sts., Ritner to Geary Sts.
Schuylkill River; Point Breeze Gas Works; clay pits; dump, Curb heights, contour lines (1ft), buildings in street lines
|
| 272-04 HP |
|
Plan for placing on City Plan Dover Street from Porter to Shunk Street and Ernest Street from 28th to Dover Street. [Ordinance June 11, 1903; survey returned June 22, 1903; confirmed Aug. 3, 1914] | Nobré, John M. | 1903 |
Mounted
10 x 16 in.
|
South Philadelphia
Curb elevations
|
| 272-05 HP |
|
Plan revising the grades of Passyunk Avenue from Schuylkill Avenue to the Schuylkill River. [Ordinance June 8, 1909; confirmed Oct. 4, 1909] | Nobré, John M. | 1909 |
Mounted
11 x 21 in.
|
South Philadelphia
Curb elevations
|
| 272-z HP |
|
Plan vacating old Passyunk Road from Twenty-ninth to Schuylkill River, in the Thirty-sixth Ward, Philadelphia. | Daly, Thomas | 1893 |
Mounted
17 x 41 in.
|
South Philadelphia, vicinity of 30th St. and Porter St.
Point Breeze Gas Works, river bank
|
| 273-w HP |
|
Profile of part of State Road in Montgomery County | Not named | 1873 |
Paper
11 x 135 in.
1 inch = 200 feet
|
State Road in Montgomery County, from City Ave. to Penn St.
Profile view of road and original land surface; cross streets and property owners
|
| 273-x HP |
|
Profile to accompany plans of the Bryn Mawr State Road - part in City of Philadelphia | Hancock, George W. | 1873 |
Paper
22 x 68 in.
1 inch = 80 feet
|
State Road in Philadelphia, from Highland Ave. to City Ave.
George's Run. Profile view of road and original land surface.
|
| 273-y HP |
|
Plan of that Part of Bryn Mawr State Road within the limits of Montgomery County | Not named | 1873 |
Tracing
21 x 129 in.
1 inch = 200 feet
|
Bryn Mawr State Road in Montgomery County, from City Ave. to Gulf (now Gulph) Road.
Road courses and distances, property owners, creek crossings
|
| 273-z HP |
|
Plan of that part of Bryn Mawr State Road within the limits of Philadelphia County made agreeably to an Act of the General Assembly of the Commonwealth of Pennsylvania approved the eighteenth day of April A.D.1873. [Attachment: Report of commissioners to lay out road] | Hancock, George W. | 1873 |
Mounted
51 x 42 in.
1 inch = 50 feet
|
West Philadelphia. Bryn Mawr Avenue, Fairmount Park line to City Ave.
Topography over road lines only, property owners, building footprints
|
| 273-z HP attachment |
|
[Commissioners report relating to a proposed state road from Montgomery Avenue in Lower Merion Township, Montgomery County, to Belmont Avenue in Philadelphia, as depicted in plan 273-z_HP] | 1873 |
Paper
13 x 9 in.
|
West Philadelphia. Bryn Mawr Avenue, Fairmount Park line to City Ave.
Attachment
|
|
| 274-01 MTD |
|
Plan showing topography and revision of lines and grades of the Seventeenth Section of the survey and regulation of the late Township of Bristol, Twenty-second Ward, City of Philadelphia [Resolution, no date; no confirmation date] | Not named | 1880 ca. |
Mounted
43 x 79 in.
|
22nd Ward, 17th Section, Bristol. Bounded roughly by Cheltenham to Somerville Aves., Front St. to Tacony Creek
Topography, building footprints, mill races, Tacony Creek and tributary streams. Plan seems to be a draft and incomplete.
|
| 274-02 MTD |
|
Plan of the Seventeenth Section of survey and regulation of the late Township of Bristol, Twenty-second Ward, City of Philadelphia [Resolution March 16, 1870; confirmed June 19, 1876] | Lightfoot, Jesse | 1870 |
Mounted
42 x 78 in.
|
22nd Ward, 17th Section, Bristol. Bounded by Cheltenham to Somerville Aves., F. St. to Front St.
Tacony Creek and tributary streams, building footprints, curb elevations, railroad, old roads
|
| 274-03 MTD |
|
Plan for placing Wentz Street on the City Plan between Clarkson Ave. and Tabor St. in the 22nd Ward, Phil'a [Ordinance Nov. 17, 1890; survey returned Sept. 19, 1892; confirmed Dec. 19, 1892] | Brinton, Walter | 1892 |
Mounted
20 X 12 in.
|
Bounded by Front St. to Maple Ave., Clarkson Ave. to Fisher Ave.
Curb elevations, building footprints, railroad
|
| 274-05 MTD |
|
Plan of the revision of lines and grades on Water St. (late Wentz St.) from Tabor St. to a point about 200 ft. north. Forty-second Ward, Philadelphia [Ordinance Dec. 4, 1901; survey returned Feb. 3, 1902; confirmed Feb. 3, 1902] | Brinton, Walter | 1902 |
Mounted
16 x 12 in.
|
Bounded by Clarkson Ave. to Tabor St., Newtown Ave. to Ella St.
Curb elevations, building footprints
|
| 274-06 MTD |
|
Plan of the revision of lines and grades on portion of City Plan No. 274, Thirty-fifth Ward, Philadelphia [Ordinances July 17, 1891 and March 15, 1892; survey returned July 21, 1902; confirmed Aug. 18, 1902] | Brinton, Walter | 1902 |
Mounted
15 x 30 in.
|
Bounded by Cheltenham Ave. to Godfrey Ave., Tacony Creek to Rising Sun Ave. (formerly Kensington and Oxford Turnpike)
Topography, building footprints, railroad
|
| 274-08 MTD |
|
Plan of the revision of lines and grades on a portion of City Plan No. 274 35th and 42nd Ward Philadelphia [Ordinances 1892, 1902 and 1904; survey returned March 2, 1908; confirmed March 2, 1908] | Brinton, Walter | 1908 |
Mounted
51 x 49 in.
|
Northeast Philadelphia. Bounded by Tabor St., Adams Ave., Champlost St., and Front St.
Topography, Tacony Creek and tributary streams, building footprints, ponds, railroad
|
| 274-09 MTD tracing |
|
Plan for placing on City Plan Tacony Creek Park, 35th and 42nd Wards, Philadelphia [Ordinance June 20, 1908; survey returned Sept. 21, 1908; confirmed Nov. 16, 1908] | Brinton, Walter | 1908 |
Tracing
31 x 67 in.
1 inch = 100 feet
|
Tacony Creek Park. Area on both sides of Tacony Creek, bounded by Tabor Rd. to Cheltenham Ave.
Topography, streams, ponds, mill races, building footprints
|
| 275-02 MTD |
|
Plan of the survey and regulation of the Seventeenth Section, Twenty-first Ward, City of Philadelphia [Ordinance Sept. 19, 1870; confirmed 1874 and 1879] | Levering, John H. | 1874 |
Mounted
57 x 43 in.
|
21st Ward, 17th Section. Bounded by Ridge Ave. to Schuylkill River, Domino Ave. (now Domino Lane) to Cinnaminson St.
Topography, streams, building footprints, Manayunk Canal
|
| 275-17 CP |
|
Plan of the revision of lines and grades of that portion of City Plan No. 275 bounded by Ridge Avenue, Cinnaminson Street, Silverwood Street, parker Avenue, Umbria Street … Schuylkill River … and the N.W. side of Domino Lane, in the Twenty-first Ward, Philadelphia. [Ordinance Dec. 28. 1905; confirmed Sept. 8, 1924] | Granlund, K. W. | 1924 |
Tracing
41 x 56 in.
|
Roxborough. Bounded roughly by Ridge Ave. to Schuylkill River, Domino Lane to Cinnaminson and Fountain Sts.
Topography, streams (some sections piped underground), Manayunk Canal, building footprints
|
| 276-z HP |
|
Plan of line and grade regulations of the Twenty-first Section of the Twenty-third Ward Philadelphia authorized by resolution of Councils approved December 13th, 1873 | Not named | 1873 ca. |
Mounted
39 x 79 in.
1 inch = 100 feet
|
23rd Ward, 21st Section. Frankford Ave to Bustleton Turnpike; Longshore to Bligh St.
Curb heights, creeks
|
| 277-z HP |
|
Plan of line and grade regulations of the Twenty-third Section of the Twenty-third Ward Philadelphia authorized by resolution of Councils approved December 13th, 1873 | Not named | 1873 ca. |
Mounted
28 x 67 in.
1 inch = 100 feet
|
23rd Ward, 23rd Section. Crabtree to Bustleton Turnpike, Bligh to Hartel St.
Sandy Run, curb heights, creeks
|
| 278-01 MTD |
|
Plan of line and grade regulations of the Twenty-second section of the Twenty-third Ward, Philada. [Ordinance Oct. 21, 1872; confirmed March 3, 1873] | Not named | 1873 |
Mounted
42 x 84 in.
|
23rd Ward, 22nd Section. Bounded by Longshore St., Delaware River, Robbins St.. and Frankford Ave.
Streams, curb elevations
|
| 278-02 MTD |
|
Plan of the revision of line and grade regulations on the Twenty-Second Section in the Twenty-third Ward Philadelphia [Ordinances Dec. 31, 1880 and July 10, 1885; confirmed March 29, 1886] | Webster, George S. | 1886 |
Mounted
42 x 80 in.
|
23rd Ward, 22nd Section. Bounded by Longshore St., Delaware River, Robbins St.. and Frankford Ave.
Topography, streams, building footprints
|
| 278-15 MTD |
|
Plan to place on the city plan Glenview Street from Algard St. to Frankford Ave. Forty-first Ward Phila. [Ordinances Nov. 28, 1914 and June 10, 1915. confirmed Nov. 1, 1915] | Webster, John H., Jr. | 1915 |
Tracing
16 x 23 in.
|
Northeast Philadelphia. Bounded by Longshore St. to Knorr St., Frankford Ave. to Algard St.
Topography, Little Wissinoming Creek
|
| 279-01 HP |
|
Plan showing revisions of lines and grades on Plan 279 authorized by an ordinance of Councils approved Dec 19th 1892. Approved by Board of Surveyors. [Portion confirmed 1899] | Not named | 1892 ca. |
Mounted
44 x 76 in.
1 inch = 100 feet
|
South Philadelphia. 25th St. to Schuylkill River, Tasker to Ritner Sts.
Topography, Rambo's Rock, curb heights, creeks, houses, property lines
|
| 279-02 HP |
|
Plan of lines and grades between Tasker, Ritner, and Twenty-sixth Streets, and the Schuylkill River 26th Ward. [Authorized April 15, 1872; confirmed Oct. 19, 1874] | Daly, Thomas | 1874 |
Tracing
46 x 68 in.
|
South Philadelphia. Bounded by Tasker, Ritner and 26th Sts. and the Schuylkill River
Topography, streams, river bank, clay pits
|
| 279-03 HP |
|
Plan of the revision of the lines and grades on City Plan No. 279 bounded by Tasker Street, 26th Street, Wolf Street and Schuylkill River. 36th Ward Philadelphia [Ordinances Dec. 19, 1892 and Dec. 28, 1895; confirmed March 29, 1909] | Nobré, John M. | 1909 |
Mounted
42 x 82 in.
|
South Philadelphia. Bounded by Tasker St., 26th St., Wolf St. and Schuylkill River.
Rambo's Rocks, curb elevations, river banks, railroad
|
| 279-04 MTD |
|
Plan revising the lines & grades on a portion of City Plan No. 279 bounded by Tasker Street, Thirty-fifth Street, Wolf Street and Schuylkill River. Twenty-sixth Ward. [Ordinance March 2, 1907; confirmed Nov. 18, 1907] | Nobré, John M. | 1907 |
Mounted
29 x 54 in.
|
South Philadelphia. Bounded by Tasker St., 35th St., Wolf St. and Schuylkill River.
Curb elevations, railroad, river bank, Rambo's rocks, building footprints
|
