Plan colored to show character of cartway paving compiled from office records and field examinations. Feb. 13, 1912. Cartway widths shown in black. Small alleys and courts not shown.
Plan (adjusted)
Title:
Plan colored to show character of cartway paving compiled from office records and field examinations. Feb. 13, 1912. Cartway widths shown in black. Small alleys and courts not shown.
Creator:
Not named
Date Created:
1912, upd. 1944 ca.
PhysicalFormat:
62 x 38 in.
Coverage:
West Philadelphia. City Plan area 143
Identifier:
SD7th-Paving-CP143
Media:
Mounted
Map Features:
Paving types shown include: granite or Belgian blocks, asphalt or asphalt blocks, granolithic, vitrified bricks or slag bricks, macadam, wood blocks, and cobble or rubble. Also shows topography with five-foot contours, Pennsylvania Hospital for the Insane
Scale:
1 inch = 200 feet
Source:
Image File(s):
SD7th-Paving-CP143.ecw
|
|
||||
